- Description
Description:
Position:Driver(LH Left ) or Passenger(RH Right) Rear
ABS Sensor Included: No
Wiring Harness Included: No
Number Of Mounting Bolts To Knuckle: 4
Number Of Lug Bolts Included: 0
Number Of Flange Bolts Included: 0
Driven Or Non-Driven: Non-Driven
Number Of Splines: 0
ABS Ring Type: Encoder
Total Hub Diameter (in): 5.47 Inch
Total Hub Diameter (mm): 138.8mm
Hub Centerbore Diameter (in): 3.94 Inch
Hub Centerbore Diameter (mm): 100mm
Total Hub Height (in): 6.75 Inch
Total Hub Height (mm): 171.45mm
Flange Diameter (in): 6.22 Inch
Flange Diameter (mm): 158mm
Flange Offset (in): 2.712 Inch
Flange Offset (mm): 68.9mm
Flange Shape: Modified
Material: Steel
Bearing Type: Ball
Hub Pilot Diameter (in): 2.87 Inch
Hub Pilot Diameter (mm): 72.9mm
Fit 2015 2016 2017 2018 2019 Honda Fit.
Position:Driver(LH Left ) or Passenger(RH Right) Rear
ABS Sensor Included: No
Wiring Harness Included: No
Number Of Mounting Bolts To Knuckle: 4
Number Of Lug Bolts Included: 0
Number Of Flange Bolts Included: 0
Driven Or Non-Driven: Non-Driven
Number Of Splines: 0
ABS Ring Type: Encoder
Total Hub Diameter (in): 5.47 Inch
Total Hub Diameter (mm): 138.8mm
Hub Centerbore Diameter (in): 3.94 Inch
Hub Centerbore Diameter (mm): 100mm
Total Hub Height (in): 6.75 Inch
Total Hub Height (mm): 171.45mm
Flange Diameter (in): 6.22 Inch
Flange Diameter (mm): 158mm
Flange Offset (in): 2.712 Inch
Flange Offset (mm): 68.9mm
Flange Shape: Modified
Material: Steel
Bearing Type: Ball
Hub Pilot Diameter (in): 2.87 Inch
Hub Pilot Diameter (mm): 72.9mm
Fit 2015 2016 2017 2018 2019 Honda Fit.
