- Description
Lug Bolt Thread Size: M12-1.25
Flange Bolt Size (in): 1.271 Inch
Flange Bolt Thread Size: M12-1.50
Total Hub Diameter (in): 5.590 Inch
Hub Centerbore Diameter (in): 4.492 Inch
Total Hub Height (in): 3.433 Inch
Flange Diameter (in): 5.59 Inch
Flange Offset (in): 1.594 Inch
Outer Ring Width (in): 1.69 Inch
Hub Pilot Diameter (in): 3.31 Inch
Fit the Following Vehicles:
Fit 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 Chrysler Sebring
Fit 1995 1996 1997 1998 Eagle Talon
Fit 1995 1996 1997 1998 1999 2000 Dodge Avenger
Fit 2001 2002 2003 2004 2005 Dodge Stratus
Fit 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 Mitsubishi Eclipse
Fit 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 Mitsubishi Galant
Flange Bolt Size (in): 1.271 Inch
Flange Bolt Thread Size: M12-1.50
Total Hub Diameter (in): 5.590 Inch
Hub Centerbore Diameter (in): 4.492 Inch
Total Hub Height (in): 3.433 Inch
Flange Diameter (in): 5.59 Inch
Flange Offset (in): 1.594 Inch
Outer Ring Width (in): 1.69 Inch
Hub Pilot Diameter (in): 3.31 Inch
Fit the Following Vehicles:
Fit 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 Chrysler Sebring
Fit 1995 1996 1997 1998 Eagle Talon
Fit 1995 1996 1997 1998 1999 2000 Dodge Avenger
Fit 2001 2002 2003 2004 2005 Dodge Stratus
Fit 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 Mitsubishi Eclipse
Fit 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 Mitsubishi Galant
