- Description
Fit the Following Vehicles:
1995 1996 1997 1998 1999 2000 2001 2002 2003 Ford Explorer
2001 2002 2003 2004 2005 Ford Explorer Sport Trac
2003 2004 2005 2006 2007 2008 2009 Ford Ranger
2003 2004 Mazda B3000
2003 2004 2005 2006 2007 2008 2009 Mazda B4000
OE Part Numbers:
1F80-33-061,3L24-1104AB,WB15003,
WB15052,1F6033061 1F8033061, 3L241104AB,
3L241104AC, 515051, WA515051, 29515051, 515052, 515003, BR930252; BR930345, BR930452.
Features:
Position:Driver(LH Left) or Passenger (RH Right) Side Front
ABS Sensor Included: Yes
Wiring Harness Included: Yes
Number Of Lug Bolts Included: 5
Driven Or Non-Driven: Driven
ABS Ring Type: Sensor
Number Of Mounting Bolts To Knuckle: 3
Number Of Splines: 27
Number Of ABS Sensor Ring Teeth: 54
Total Hub Diameter (in): 5.88 Inch
Hub Centerbore Diameter (in): 4.5 Inch
Total Hub Height (in): 4.77 Inch
Flange Diameter (in): 2.83 Inch
Flange Offset (in): 2.20 Inch
Flange Bolt Size (in): 1.48 Inch
Hub Pilot Diameter (in): 3.94 Inch
Flange Bolt Thread Size: 1/2-20 Inch
ABS Connector Shape: Round
Material: Steel
1995 1996 1997 1998 1999 2000 2001 2002 2003 Ford Explorer
2001 2002 2003 2004 2005 Ford Explorer Sport Trac
2003 2004 2005 2006 2007 2008 2009 Ford Ranger
2003 2004 Mazda B3000
2003 2004 2005 2006 2007 2008 2009 Mazda B4000
OE Part Numbers:
1F80-33-061,3L24-1104AB,WB15003,
WB15052,1F6033061 1F8033061, 3L241104AB,
3L241104AC, 515051, WA515051, 29515051, 515052, 515003, BR930252; BR930345, BR930452.
Features:
Position:Driver(LH Left) or Passenger (RH Right) Side Front
ABS Sensor Included: Yes
Wiring Harness Included: Yes
Number Of Lug Bolts Included: 5
Driven Or Non-Driven: Driven
ABS Ring Type: Sensor
Number Of Mounting Bolts To Knuckle: 3
Number Of Splines: 27
Number Of ABS Sensor Ring Teeth: 54
Total Hub Diameter (in): 5.88 Inch
Hub Centerbore Diameter (in): 4.5 Inch
Total Hub Height (in): 4.77 Inch
Flange Diameter (in): 2.83 Inch
Flange Offset (in): 2.20 Inch
Flange Bolt Size (in): 1.48 Inch
Hub Pilot Diameter (in): 3.94 Inch
Flange Bolt Thread Size: 1/2-20 Inch
ABS Connector Shape: Round
Material: Steel
