Everything You Need To Know About Wheel Bearings


Visionary fi lms set in the technologically advanced future have long imagined cars that ride around on frictionless orbs similar to Star Wars’ BB-8. We aren’t there yet, as cars still use wheels and tires to tackle terrain for now, but the modern automobile would not be possible without a diff erent type of roller balls. We’re talking about ball bearings.

Behind virtually every wheel on every newish vehicle, there is a set of tiny ball bearings that keep the wheels smoothly rotating without interruption. They’re unsung heroes when it comes to discussions of a car’s primary parts, but their importance cannot be overstated.

Although these small balls are not a part of the regular maintenance cycle, they do eventually go bad, so it’s important to know how they work when it comes time for repairs. For that reason, The Drive’s reliable informational team has assembled the answers to all your questions in one place. Let’s explore.

What Are Wheel Bearings?

Wheel bearings are small metal balls held within small rings that are designed to reduce rolling friction and allow the car’s wheels to spin freely, all while sustaining the vehicle’s weight.

Where Are Wheel Bearings Located?

A wheel bearing is located within the wheel hub, which connects the wheel to the axle. Each wheel has its own set of wheel bearings.

The suspension, brakes, and wheel hub assembly of a car with the wheel removed.

The bearing is inside the wheel hub assembly., Depositphotos


Ball Bearings Vs. Roller Bearings

Two of the most common types of wheel bearings are ball and roller. One style of wheel bearings used rollers, which were basically a series of small cylinders placed within a tapered circular housing. Roller bearings typically are not sealed, which is good for service but bad for susceptibility to contamination. Ball bearings, however, use miniature balls with small contact points for rolling ease. Ball bearings are typically sealed, which is great for keeping contamination out, but they often cannot be serviced.

How Long Do Wheel Bearings Last?

The lifespan of your wheel bearings will depend on the manufacturer, the day-to-day operating conditions, and driving loads, but they are generally expected to last at least 75,000-100,000 miles.

Symptoms of a Bad Wheel Bearing

The good thing about a wheel bearing is you’ll know when it goes bad, thanks to a few obvious symptoms. These are the tell-tale signs you need to inspect yours:

Irregular Noises

The most common symptom of bad wheel bearings is the weird noise they produce when something is off . You might hear humming, whirring, rumbling, grinding, or clicking, depending on how the wheel bearing is failing.

Uneven Tire Wear

As the ball bearings wear down, they will start to loosen up within their housings and/or lose some of their eff ectiveness. Because of this, the tires could wear down unevenly.

Loose Steering Feel

No, the steering wheel itself won’t feel loose, but the steering feel might. If a bearing goes bad, it might create a bit of play within the wheel assembly. If this occurs, your steering might feel more vague than normal.

Vibrations

If a wheel bearing seal is broken and the insides become contaminated with hard particles, or it has simply worn down over time, it could cause a rougher-than-usual ride and vibrations.

Wheel Lock

Most modern wheel bearings are sealed and for good reason. If any dirt, debris, or other contamination gets into the bearings, it could reduce lubrication and increase friction. If it gets too hot, or there’s too much debris in the bearings, they could start to lock up or grind. If the bearings lock up, the wheel could lock up.

Traction Control or ABS Malfunctioning

Pretty much all new wheel hub assemblies come equipped with built-in sensors that inform the traction control, ABS, stability control, and other driver-assistance systems. If something within the wheel bearing isn’t functioning in proper form, it could cause the systems to malfunction, or throw and code and warning light

A wheel hub assembly on a gray background.

Replace the entire wheel hub assembly to replace the wheel bearings., Depositphotos

Can Wheel Bearings Be Serviced?

The best thing to do with a bad wheel bearing is to replace it, along with the others to ensure even and balanced driving. The wheel bearings typically come as part of a larger wheel hub assembly package.

A Quick Overview of How To Remove a Wheel Hub Assembly

Each car is diff erent and might require diff erent steps, but these are the general steps you will go through when removing a wheel hub assembly.

  1. With the vehicle still on the ground, use a breaker bar or impact wrench to loosen the wheel hub nut, then the lug nuts.
  1. Jack up the vehicle and insert your jack stands.

  2. Remove the wheel and set it aside.

  3. Remove the brake caliper and place it somewhere that does not put stress on the brake line.
  1. Remove the rotor.

  2. Remove the axle nut.

  3. Unplug the hub assembly cord.

  4. Remove any bolts on the wheel hub assembly.

  5. Follow the manufacturer’s recommendations for removing the old hub assembly.

    Many require special tools that should be used to avoid damaging other parts of the vehicle. Seriously, the wheel bearing puller tool will make this job much simpler.

  6. As you remove the wheel bearing, be cognizant of the axle and avoid letting it drop, get dirty, or put stress on any other parts.

  7. Clean off any corrosion found on the involved parts.

  8. To replace the old hub with the new hub, insert the new hub (with a press, if necessary), replace the old axle nut, and follow the previous steps in reverse.

Note 1: When replacing the hub, you might want to use anti-seize to prevent future difficulties.

Note 2: With everything removed, this is a great time to perform inspections on the suspension and brakes.

Note 3: If you replace one bearing, you should replace the others.

Tips For Hub Removal

Wheel hub assemblies are oft en extremely stubborn to remove. If you’re already in the middle of the job but don’t have a puller tool, these other tools and methods might be able to help. Just use extreme caution not to damage anything, and always use necessary safety precautions.

  • Slide hammer
  • Rubber mallet
  • Heat and metal hammer
  • Penetrating spray

FAQs About Wheel Bearing

Q. How Do You Check Wheel Bearings?

A. The only easy checks for bad wheel bearings include a bit of assumption. To start, you want to listen for odd sounds such as humming, whirring, or grinding coming from the suspected wheel. If you hear something and can identify the source to a wheel, you can then jack the car up and check the wheel for movement, slack, or play in its linkage to the car. You can do this by grabbing the wheel by each side and shift ing forward and back or side to side.

Q. Can You Drive a Car With a Bad Wheel Bearing?

A. The car might be able to drive, but we do not recommend ever driving with a bad wheel bearing. If you notice symptoms and suspect a bad bearing, immediately drive home or to the repair shop.

Q. What Can Happen If You Have a Bad Wheel Bearing?

A. In one of the worst-case scenarios, the wheel could lock up while driving. That is to say that driving with a bad wheel bearing could be potentially very dangerous.

Q. How Much Does It Cost To Replace a Bad Wheel Bearing?

A. Depending on the car, the average cost of a single wheel hub assembly, not just a bearing, will likely land between $100-300. If you do the job on your own, multiply that by the number of hubs you’re replacing. If you’re taking it to a garage, multiply that number, then add the cost of labor. It won’t be cheap.
